HEC-F6 Series

Publish Time：2012/7/25 | Click：881

Electrical characteristics ：

Type	HEC500V-F6
Rated Current	0~±10mA
Linear Range	0～±14mA
Output Current	0~25mA
Load resistance	input current ±10mA, 100~350Ω supply voltage ±15V
	input current ±14mA, 100~190Ω supply voltage ±15V
Accuracy	±0.6%
Degree of Linearity	＜0.2%
Turn Ratio	2500:1000
Offset Voltage	±0.1mA ±0.20mA(max)
Temperature Drift	±0.20mA ±0.64mA(max ) -10 ℃ ～ +70 ℃
Response Time	＜40μS
Power Supply	± 12V 、± 15V （± 5% ）
Current Consumption	10mA plus output current
Isolation	2.5KV DC
Internal Resistance	original coil 250Ω	secondary coil 110Ω
Operating Temperature Range	0℃ ～ +70℃
Storage Temperature Range	-10 ℃ ～ +85 ℃
