HEC-F3 Series(Single-phase)

Publish Time：2012/7/25 | Click：820

Electrical characteristics ：

Type	HEC1Vac…1000Vac-F3
Rated Voltage	1Vac…1000Vac
Output Voltage	±5V ?(0-20mA or 4-20mA output current)
Accuracy	±0.5%
Input Frequent Response	20-500KHz
Offset Voltage	＜10mV
Temperature Drift	0.05%/ ℃
Response Time	＜ 400ms
Power Supply	± 12V、± 24V （± 5% ）
Current Consumption	±10mA
Isolation	2.5KV DC
Operating Temperature Range	0 ℃ ～ +50 ℃
Storage Temperature Range	-10 ℃ ～ +70 ℃
