HEC-F2 Series

Publish Time：2012/7/25 | Click：912

Electrical characteristics ：

Type	HEC75mV…1000V-F2
Rated Voltage	75mV…1000V
Output Voltage	±5V or 0-20mA/4-20mA output current
Accuracy	±0.2%
Input Frequent Response	0-20KHz
Offset Voltage	＜10mV
Temperature Drift	0.02%/ ℃
Response Time	＜ 1ms
Power Supply	± 12V （± 5% ）
Current Consumption	±10mA
Isolation	2.5KV DC
Operating Temperature Range	0 ℃ ～ +50 ℃
Storage Temperature Range	-10 ℃ ～ +70 ℃
